Samples of Coating Tablets
BGB-D Coating Machine
Based on BGB-C series coating machine, we add CIP system (clean-in-place), this system makes the cleaning work automatically and very easy.
With CIP cleaning system, the coating machine has the following features
1. Different parts of the main machine are equipped with a number of nozzles for cleaning machine
2. Configured the independent cleaning liquid booster distribution station to make sure the pressure of cleaning liquid form every spray head get up to 0.6Mpa and wash the coating machine effectively.
3. Configured the cycle cleaning and drainage systems for the cleaning process to choose
4. PLC control, can program a number of cleaning procedures
5. PLC control, to blow each nozzle dried by compressed air.
6. PLC control，implement full automatic washing and drying process.
|Production capacity (kgs/batch)||75||150||350|
|Motor power of main machine (kw)||1.1||2.2||4|
|Hot air temperature||20℃--80℃|
|Filtration accuracyof hot air(μm)||0.5 μm (100000 grade)|
|Hot air motor power||1.1||1.1||2.2|
|Exhaust motor power||3||5.5||7.5|
|Dust collector power||0.37|
|Peristaltic pump power||0.18|
|Motor power of cleaning pump(kw)||3||4||4|
|Dimension of main machine(mm)||1350x1010x1630||1570x1260x1950||2000x1560x2300|
|Weight of main machine (kg)||650||1100||1700|
Details of Tablet Coating Machine
1. coating condition in the tablet coating machine
2. patent steamline plate of tablet coating machine
