DWJ-2000S5-D Lab Scale Multi-functional Dropping Pill Machine
DWJ-2000S5-D Lab Multi-functional dropping pill machine is a modified form of the DWJ-2000S, the top is open for people to observe, and especially suitable for teaching presentation, it can make 70-600mg pills and can adjust the size of pill on line.
Photos of Dripping Pills
Features
DWJ-2000S5-D Lab Multi-functional dropping pill machine is a modified form of the DWJ-2000S, the top is open for people to observe, and especially suitable for teaching presentation, it can make 70-600mg pills and can adjust the size of pill on line.
Main Technical Parameter
| Working voltage | 220V |
| Power | 1.8Kw |
| Configuration | 1-8 holes dripping head or 1-3 holes dripping head(large pill) |
| Tank capacity | 600ml |
| pill weight | 5-600mg(diameter:1-10mm) |
| Outer air supply | ≧0.5Mpa |
| Mixing speed | 0-1400 rpm |
| cooling machinery | 1/3 Hp |
| Temperature controlling | Medicine liquid, oil bath, cooling, dripping plate, tube mouth |
| Dimension | 750mmX600mmX1900mm |
| Weight | 130 Kg |
