Cartoner Machine HD300

blisters, bottles, and little things etc.

Can complete the following functions automatically: Feeding, Leaflet folding, Carton opening,Blister inserting,Leaflet inserting, Batch number on cartons, Cartons sealing, etc.

Special functions: Double pushers, one is for inserting blisters, the other is for inserting leaflets. This design can guarantee the safety of products.

Advanced detection system: If no blister, will no leaflet; If no leaflet, will no cartons sucked; lf no carton, will no pushing of the pushers.


Share
product description

Max   Speed

230cartons/min   (for 60ml bottle)

Carton   size (LxWxH)

85×35×15~145×72×60mm3

Leaflet   size (Lxw)

130×130~170×260mm2

Power

Supply:   380V/3-Phase / AC /50Hz or according to the customers' requirements Consumption:   About 5kw

Air

Pressure:0.6-0.9Mpa

Consumption:   <0.67-0.9m3/min

Dimension   (LxWxH)

5000×2000×2100mm

Weight

About 2500kg

Noise

<75dB
